Fudia industrial grade IDE Flash Modules FDM700P series are non-volatile, solid state data storage disk. Given the advantages of lower power consumption, greater ruggedness, higher MTBF and other attracting features, Solid State Drive (SSD) is gradually becoming a mainstream to replace conventional Hard Disk Drive (HDD). Due to lack of any mechanical components, SSD provides a more robust and cost effective storage solution for any embedded application. Since Fudia FDM700P series IDE Flash Modules come with a standard ATA interface which is fully compatible with traditional HDD, designers will find Fudia industrial grade IDE Flash Modules as an easy solution for integration in PC-based systems. |
||
-文字藝術師.files/image007.png) |
||
| Specifications | ||
| Flash Type | SLC | MLC |
| 43 n.m. | 32 n.m. | |
| Interface | Standard ATA / IDE Bus Interface 512 Bytes / Sector | |
| Intelligent ATA / IDE Module | ||
| Capacity | 44 pins : 1 GB ~ 16 GB | 44 pins : 2 GB ~ 64 GB * |
| ATA command set compatible | ||
| Read/Write (Max.) Performance | Read: 86 MB/s | Read: 80 MB/s |
| Write: 80 MB/s | Write: 45 MB/s | |
| Standard Female IDE Connector | 44 pins Vertical Type | |
| Operation Temperature | Normal temperature series → 0 ~ +70°C | |
| Wide temperature series → -40 ~ +85°C | ||
| StorageTemperature | Normal temperature series → -40 ~ +85°C | |
| Wide temperature series → -40 ~ +85°C | ||
| Intelligent ATA/IDE Module | Implements dynamic wear-leveling algorithms and static wear- leveling algorithms to increase endurance of flash media. | |
| Embedded Flash File System. | ||
| ECC corrects up to 48 random bits error per 512 bytes. | ||
| Data Transfer Mode | PIO mode 4 | |
| Multiword DMA mode 2 | ||
| Ultra DMA mode 6 | ||
| Operating voltage | DC 3.3 V / 5.0 V | |
| Certificates Acquired | RoHS \ WHQL \ CE \ FCC | |
| Remarks | ||
| *MLC products will be only produced upon requested. | ||
| ** Only 44 pins vertical type has housing | ||
